All Features

All Features

MicroCore 2026 Standard Edition · 23 Key Features Across Operations, Measurement, Compensation, and Intelligence

01

Basic Operations & Imaging

Deployment, Interface, and Imaging Experience

🚀

Install software with one click

One-click automatic installation and registration of the full software stack, including dependencies and driver components, with no manual intervention required.

Full-stack automated deployment

🖼️

Multiple UI Layouts

30/130/230/500K cameras adapt to 4 layouts for lossless full-screen display without manual cropping.

Lossless display

🎛️

Hide Function Buttons

Hide function buttons on demand to adapt to different scenarios, reduce training time, and deliver a clean, efficient interface.

Minimalist Interface

Convenient image zoom

Zoom the full map with the mouse wheel for intuitive, efficient operation—replacing traditional magnifying glass tools that only show local areas.

Intuitive

🎯

Powerful edge detection

Weak edge repeatability: 3 μm. Built-in burr, color, and grayscale filtering ensures multi-level accuracy.

Weak edge <3μm

💡

One-click intelligent auto-lighting

Algorithm-adaptive workpiece feature detection: One-click optimal configuration for surface, contour, and coaxial lighting.

Smart Lighting

✨

High-Definition Image Enhancement

Proprietary AI image enhancement algorithm delivers sharper images on the same hardware without compromising accuracy.

AI-Enhanced

🧪

Intelligent Image Optimization

High-performance image processing algorithms that enhance image quality and edge effects while improving measurement stability.

High-Definition Edge

02

Smart Positioning and Measurement

Find it, Pinpoint it, Test it all.

🧩

Place freely · No fixtures required

Robust coarse localization via image feature matching for high-precision positioning and measurement, regardless of product orientation.

Exempt Fixture

🔄

Array repositioning

Global registration plus secondary fine matching automatically corrects displacement and angular errors to fix misalignment.

Stable Array

Proprietary Focusing Algorithm

Focus repeatability: 1-3 μm; edge detection repeatability up to 1 μm, ensuring micron-level precision.

1-3μm

📄

Import CAD for Measurement

One-click import of CAD drawings: automatically recognizes elements, dimensions, and tolerances to generate measurement items instantly.

No manual entry required

Seamless multi-sensor fusion

Integrated imaging, probe, and laser systems enable full-dimensional composite inspection in a single setup.

Composite Measurement

Higher-precision composite measurement

Proprietary positioning and fitting algorithms with dual linear compensation achieve repeatability of < 3μm and a deviation of 5μm.

<3μm

03

Precision Compensation and Interaction

Correct errors, integrate systems

🛠️

Self-developed lens compensation

9/16/25 circle calibration algorithm corrects radial and tangential distortion and magnification error, reducing edge deviation from 0.012mm to 0.002mm.

Edge 0.002mm

🔘

Polarity calibration

Eliminate diameter measurement errors between solid and hollow circles (6μm calibration for consistency) to reduce lens and lighting requirements.

Consistent brightness

🧿

Laser face compensation

Calibrate flatness error of large-format workbench glass with laser measurement accuracy within 3 μm.

≤3μm

📈

High-Stability Contour Tracking

One-click contour selection for tracking; fast, precise, and continuous even with artifacts or blurred edges.

Select in one step

🔗

Multi-protocol Interoperability

Supports multiple protocols including MES, IO, and serial ports; enables real-time data upload and sharing with multi-format export.

Seamlessly integrated

04

Advanced Intelligent Features

Advanced tooling and intelligent capabilities

Scan to Measure

Supports dual-mode scanning with barcode scanners and cameras. Automatically identifies product information, launches the measurement program, and measures upon scan.

Start with one click

AI-powered edge detection

Deep learning-powered AI self-learning ensures stable grasping in challenging conditions: weak edges, noise, and blur.

AI Self-Learning

Intelligent contour comparison for irregular profiles

Automatically overlay actual and standard profiles to visualize compliant and out-of-tolerance areas, precisely capturing deformations.

Visual Comparison

📊

Professional Measurement Tools · Area Calculator

Irregular area calculation, defect detection, and multi-view composite measurement.

Defect Detection

⚙️

Professional Measurement Tools · Gear Measurement

Multi-tooth adaptive recognition: stable measurement of half-teeth, full teeth, and external gears; covers span over pins, tooth count, and base tangent length.

Gear Measurement

🌀

Precision Measurement Tools · Thread Measurement

Covers both straight and tapered thread measurements with simple operation, high accuracy, and stable performance.

Thread Measurement
